Innovative highlights of the exhibit：

Japan alternative digital servo control technology; 15-inch colorful touching LCD;double hydraulic system,automatic lubrication.max feeding speed 8-30m/min.

Product introduction:

The data resolution rate is 0.01mm. It has self-diagnostic function of troubles and displays the operating pattern, and has 300 program units, over 30000 different cutting positions,dynamic display of cutting and running, dynamic tracking, Powerful computer operating system with more functions and it can store and memorize things.The storage time can be up to 300,000 hours with self-maintenance of the operating system. Hydraulic components are adopted from Italy ，electrical components from France、Germany、Japan、Korea，Taiwan ball lead screw，Linear double guide rails, PLC control system are adopted to monitor all mechanical implementation,Its key parts adopt imported bearing of low maintenance.

Innovative highlights of the exhibit：

Double touch screen (with Internet of Things), simple and convenient operation; fast cutting speed, wide application range

Product introduction:

1、Imported AC servo and PLC control system are adopted to make the cutting speed of the machine faster, more accurate and more stable 2、10-inch human-machine screen double touch screen (with Internet of Things), and has a self-diagnostic function, making the operation simple and convenient; 3、With recurve structure to make the paper flat and smooth 4、This machine is suitable for a wide range of applications, such as cardboard, coated paper, kraft paper, cultural paper, double-coated paper, gold and silver cardboard, tobacco and alcohol packaging paper, aluminum foil paper, laser laser paper, etc. The King of Paper has a wide range of applications, such as cardboard, coated paper, kraft paper, cultural paper, double-coated paper, gold and silver cardboard, tobacco and alcohol packaging paper ect.

Innovative highlights of the exhibit：

Automatic, accurate and efficient paper feeding; save labor

Product introduction:

Fetch function with automatic feeding.The feed roller can quickly separate piles of paper sheets by a set height to crawl to the working table. The paper position and height of the pneumatic gripper can be detected accurately by the infrared distance security sensor, so that the whole feeding process will be accurate and efficient,and it reduces labor intensity and improves efficiency and working accuracy. Working table is equipped with air cushion device,the process of up and down is driven by the worm gear reducer.The ball screw and linear guide ensure smooth and accurate movement of the table. The movement of working table is driven by the worm gear with rack and pinion. Linear guide slider positioning makes it easy to move the working table. The machine has advantages in feeding and unloading paper automatically, accurately and efficiently. Pneumatic components are adopted from Japan and Taiwan, and electric components from France, Germany, Japan and Korea. Electrical configuration is a programmable controller. Japanese PLC can monitor all appliances of the machine, adopting NSK Bearings of low maintenance.

Innovative highlights of the exhibit：

The automatic paper unloading process is accurate and efficient, reduces labor intensity, improves labor efficiency, and improves work accuracy.

Product introduction:

Guowei full-automatic unloading paper machine series has functions of automatic recognition of paper size and location, automatic feeding and unloading paper, it can quickly transport cutting products of a variety of textures automatically to a predetermined position and remove from the working table to a base of a predetermined height automatically. The whole feeding and unloading process is accurate and efficient,and it reduces labor intensity and improves efficiency and working accuracy.Working table is equipped with air cushion device,the process of up and down is driven by the worm gear reducer.The ball screw and linear guide ensure smooth and accurate movement of the table. The movement of working table is driven by the worm gear with rack and pinion. Linear guide slider positioning makes it easy to move the working table. The machine has advantages in feeding and unloading paper automatically, accurately and efficiently. Pneumatic components are adopted from Japan and Taiwan, and electric components from France, Germany, Japan and Korea. Electrical configuration is a programmable controller. Japanese PLC can monitor all appliances of the machine, adopting NSK Bearings of low maintenance.

Innovative highlights of the exhibit：

22-inch color touch screen, CIP4 function, 1000 program groups, cutting of more than 100,000 different positions

Product introduction:

CIP4 is the computerization and automation of the printing industry. The code is to develop a common file exchange and data sharing format.Japan alternative digital servo control technology; 22-inch colorful touching LCD;double hydraulic system.The data resolution rate is 0.01mm. It has self-diagnostic function of troubles and displays the operating pattern, and has 1000 program units, over 100000 different cutting positions,dynamic display of cutting and running, dynamic tracking,max feeding speed 8-30m/min. Powerful computer operating system with more functions and it can store and memorize things.The storage time can be up to 300,000 hours with self-maintenance of the operating system. Hydraulic components are adopted from Italy ，electrical components from France、Germany、Japan、Korea，Taiwan ball lead screw，Linear double guide rails, PLC control system are adopted to monitor all mechanical implementation,Its key parts adopt imported bearing of low maintenance,Automatic fueling,automatic maintenance function.

Innovative highlights of the exhibit：

Reduce work intensity by 50%, increase labor efficiency by 20%, and increase work efficiency to 30%

Product introduction:

"Guowei" cutting production line is composed of paper feeder, microcomputer program-controlled paper cutter, automatic paper unloading machine and other equipment. The automatic paper loading machine has the function of automatic grabbing and feeding paper without manual transportation. The paper loading machine transports the paper to the cutting machine table for cutting work. After the paper is cut, the automatic paper unloading machine can quickly remove all kinds of The cut finished product of texture is automatically transported to the predetermined position and the paper is automatically unloaded from the worktable to the base of the predetermined height.This cutting line has the advantages of automatic, accurate and efficient paper feeding and unloading, and it can automatically complete various paper loading and unloading, sorting, handling, palletizing and other tasks. It has the characteristics of high production efficiency, low labor intensity, short auxiliary working time, and reduced production costs. Can provide users with a variety of specifications and different combinations of cutting production line equipment design and manufacturing.

Innovative highlights of the exhibit：

full hydraulic Cutter, it has compact.structure, small size.widely used in office and light printing business

Product introduction:

Single-phase 220V full hydraulic Cutter, it has compact,structure, small size, and nice appearance. Cutting and paper-platen system are hydraulic driven , has simpler structure, lower noise and lower power consumption than the mechanical transmission. It is suitable for cutting small paper or paper-like soft material, widely used in office and light printing business. Slot-less working table make it simple for the system running. Paper pusher is driven by the screw below the working table, its verticality and parallelism adjustment are completed independently, making the accuracy adjustment more simple. Computer system adopts colorful touch screen and programmable logic controller PLC programming control, that makes the operation more simple; the machine equipped with photoelectric safety protection devices makes the operation safer.
